Product Features

Food-grade Precision Forming：Cavity uses 304 stainless steel + food-grade silicone sealing, electro-polished surface (Ra≤0.4μm) to avoid material contamination, ensuring smooth burr-free edges compliant with direct food contact standards.

Efficient Temperature Control：Built-in ceramic heating rods and circulating water cooling, achieving ±2℃ precision control at 150-230℃ via PLC module, shortening cycle to 6-10s/cycle, 50% higher efficiency with reduced thermal degradation.

High-wear Structure Design：Wear-prone areas (closure teeth, edge slots) use YG6 cemented carbide inlay, enduring over 200,000 cycles. Automatic lubrication reduces maintenance cost by 40%, ideal for high-frequency batch production.

Quick Changeover System：Modular combination with positioning pins enables 10-min cavity replacement, supporting fast switching of box size, divider layout, etc., for multi-variety small-batch orders.

Technical Parameters

Application Areas

Cookie Packaging：Thermoforming of heart-shaped, round 异形 cookie boxes with window design and moisture-proof closure;

Filled Cookie Packaging：Precision forming of multi-grid trays, drawer-type boxes for chocolate/cream-filled cookies;

Soda Cracker Packaging：Large family-size box forming with reinforcing ribs for stacking strength;

Gift Cookie Packaging：Relief texture forming for premium gift boxes, integrating gold stamping pre-grooves and ribbon buckles.

Customization Services

Structure Customization：Tailored divider quantity/shape, closure tooth type (serrated/straight), handle grooves, etc.;

Texture Customization：Mould surface engraving for patterns, brand logos, product info, realizing integrated forming & marking;

Special Functions：Antistatic coating moulds (surface resistance 10⁶-10⁹Ω), antibacterial masterbatch compatible moulds for high-end baking packaging.

Quality Assurance

Complies with ISO 9001:2015 and HACCP, each mould undergoes four aging treatments to eliminate stress;

CMM-inspected cavity precision (tolerance ±0.05mm, Ra≤0.3μm);

14-month warranty, free insert replacement for non-human damage, lifelong cost-price supply for wearing parts, including 3 free temperature system calibrations.
